Altrace
| Altrace Main Specification: | ||
| Measurement Specifications | Measurement principle | X-ray fluorescence spectrometry |
| Measurement method | Energy dispersive | |
| Target samples | Solids, liquids, powders | |
| Measuring range | Na to U | |
| Sample cell size | Dia. 25 × 20 mm | |
| X-Ray Generator | X-ray tube | Rh target (100 W) |
| Voltage | 5 to 65 Kv | |
| Current | 4000 µA max. | |
| Cooling method | Air-cooled (with fan) | |
| Analysis region | Dia. 18mm | |
| Primary filters | Automatic exchange of 6 types (8 types when including open and the attenuator) | |
| Leakage dose rate | 0.5 µSv/h max | |
| Detector | Type | Silicon drift detector (SDD) |
| Liquid nitrogen | Not required (electronic cooling) | |
| Measurement Chamber |
Measurement atmosphere | Air, vacuum |
| Sample replacement | 48-sample autosampler | |
| Protective function | Contamination-proof cup | |
| Sample rotation function | Sample spinner included | |
| Data Processor | CPU | Intel® Core™ i5-13500 or above |
| Memory | 16 GB min. | |
| SSD | 500 GB min. | |
| Optics | Super Multi Driver | |
| PC OS | Windows® 11 Pro | |
| Software | Qualitative analysis | Measurement/analysis software |
| Quantitative analysis | Calibration curve method, matrix correction, FP method, thin-film FP method, background FP method | |
| Utilities | Automatic calibration function (energy calibration and intensity check) | |
| Others | Instrument status monitoring function, analysis results tabulation function |
|
| Installation | Temperature | 12 to 30 °C (temperature fluctuation rate 2 °C/hour max., temperature fluctuation range: ±5 °C max.) |
| Relative humidity | 40 to 70 % (No condensation) | |
| Power supply | 100 to 240 V ± 10 %, 50/60 Hz, 300 VA* | |
| Dimensions | W710 × D550 × H570 mm | |
| Weight of main unit | Approx. 110 kg | |
