CitoPress-5 Hot Cell
| c/n | : 05776327 |
Automatic, electro-hydraulic hot mounting press for 1 cylinder
Specifications
| Features | Cabinet and Tank for Hydraulic System | : Made from Stainless Steel |
| LCD display with white LED backlight | : 160 x 240 dots | |
| Controls | : Touchpad | |
| Power Supply | : 1 x 100-240 V / 50-60 Hz | |
| Length of supply cable | : 8 m | |
| Mounting Unit | Cylinder Dia | : 25, 30, 40, 50 mm or 1.25, 1.5" |
| Compression | Force on piston rod | : 50 - 350 bar / 725 - 5076 psi (in steps of 25 bar / 363 psi) |
| : When using 50 mm cylinder dia. Max force is 250 bar / 3625 psi | ||
| Heating (with pressure on) | Temperature | : 120 / 150 / 180°C (248 / 302 / 356°F) |
| Time | : Variable between 1-15 min | |
| Cooling (with pressure on) | Time | : Variable between 1-15 min |
| Rate | : High = Full Flow | |
| : Medium = 20% of full flow | ||
| : Low = 3% of full flow | ||
| Water / Air Supply | Pressure | : 1 - 10 bar / 14.5 - 145 psi |
| Inlet | : 10 mm | |
| Outlet | : 12.7 mm | |
| Electrical supply and consumption | Voltage / Frequency | : 200 - 240 V / 50 - 60 Hz or 100 - 120 V / 50 - 60 Hz |
| Power Phases | : 1-phase (N+L1+PE) or 2-phase (L1+L2+PE) | |
| Power Consumption, Idle | : 8 W | |
| Power Consumption, Max | : 1300 W | |
| Current | : 5.6 A @200-240V or 13A @100-120V | |
| Dimensions and Weight | Width | : 480 mm / 19" |
| Depth | : 560 mm / 22" | |
| Height (Mounting unit and top closure installed | : 440 mm / 17.5" | |
| Weight | : 34 kg / 75 lbs | |
| Working Environment | Temperature (Operational) | : 5 - 40°C / 41 - 104°F |
| Humidity (Non condensing) | : 0 - 95% RH |
