SMX-311M-Fi311M
Produk / Shimadzu Non Destructive Testing / Fluoroscopic System / SMX-311M-Fi311M
SMX-312M/SMX-312M-P
Specifications
| X-Ray Generator | : | Microfocus X-ray unit | |
| Maximum Tube Voltage | : | 130 kV (standard) | |
| 150 kV (optional) | |||
| Maximum Power | : | 75 W (with optional unit selected) | |
| Focal Size (Nominal) | : | Min. 7 μm (with optional unit selected) | |
| Detector | : | Image intensi er (standard) | |
| Flat panel (optional) | |||
| Maximum Sample Size | : | 200 mm dia. × 650 mm tall; 15 kg | |
| 5-Axis Table Movements | : | Left-right, forward-backward, vertical, rotation, and tilt | |
| X-Ray Shield Box | : | Interlock mechanism included | |
| X-ray leakage: Max. 1 μSv/h; | |||
| [X-RAY] indication lamp; shield box interior lighting | |||
| Power Supply | : | Single-phase, 200 V AC, 50/60 Hz, 1 kVA, 1 kVA (-P) | |
| Dimensions | : | W1700 × D1070 × H1850 mm | |
| Weight | : | About 1,650 kg |
FI-312M/FI-312M-P
Specifications
| X-Ray Generator | : | Minifocus X-ray unit | |
| Maximum Tube Voltage | : | 150 kV | |
| Maximum Power | : | 75W (standard) | |
| 355W (optional) | |||
| Focal Size (Nominal) | : | 0.1mm (standard) | |
| 0.3/0.6mm (optional) | |||
| Detector | : | Flat panel (standard) | |
| Image intensier (optional) | |||
| Maximum Sample Size | : | 200 mm dia. × 650 mm tall; 15 kg | |
| 5-Axis Table Movements | : | Left-right, forward-backward, vertical, rotation, and tilt | |
| X-Ray Shield Box | : | Interlock mechanism included | |
| X-ray leakage: Max. 1 μSv/h; | |||
| [X-RAY] indication lamp; shield box interior lighting | |||
| Power Supply | : | Single-phase, 200 V AC, 50/60 Hz, 2 kVA, 2 kVA (-P) | |
| Dimensions | : | W1700 × D1070 × H1850 mm | |
| Weight | : | About 1,650 kg |
