| X-Ray Generator |
|
: |
Sealed tube type, Rated power: 10 W |
| Max. tube voltage: 90 kV |
| Max. tube current: 250 μA |
| X-Ray Detector |
|
: |
Digital flat panel detector |
| Max. Stroke of CT Stage |
|
: |
SOD axis: 190 mm |
| Z axis: 50 mm |
| Max. Sample Size |
|
: |
160 mm dia. × H100 mm, 4 kg max. |
| Max. CT Scan Area (FOV) |
|
: |
50 mm dia. |
| Scanning Methods |
|
: |
Offset scan, CBCT |
| CT Data Acquisition Time |
|
: |
Any value from 40 sec to 30 min |
| CT Image Sizes |
|
: |
512 × 512 mm |
| 1024 × 1024 mm |
| Dimensions and Weight of Shield Box |
: |
W830 × D601 × H587 mm, 250 kg |
| Dimensions and Weight of Dedicated Desk |
: |
W1,500 × D750 × H740 mm, approx 80 kg |
| Power Requirements |
|
: |
100 V AC ±10 %, 50/60 Hz, 1 kVA |
| Max. ground resistance of 100 |
| X-Ray Leakage Rate |
|
: |
1 μSv/h max. |
